$580.00
JG-024UA Gold Nanoparticle Ink
Conductive InksAerosol Conductive Inks| Deposition: | Aerosol |
| Vehicle: | Aqueous |
| Resistivity: | 4.2E-4 to 1.9E-5 ohm-cm |
| Substrates: | Plastics, glass and metal |
| Features: | Contains a fluoropolymer for excellent adhesion and water resistance |
Water-based JG-024UA is a highly-conductive gold nanoparticle ink that is sprayable (aerosol ultrasonic atomization), excellent for fine line printing, has superior adhesion, and with added fluoropolymer is water resistant. Ideal for plastic, glass, and metal substrates.
Technical Specs
| Pigment/Loading: | Gold nanoparticles @ 40wt% |
| Vehicle: | Aqueous-based |
| Resistivity: | 4.2E-4 to 1.9E-5 ohm-cm (30min @ 140C to 5min @ 225C) |
| Substrates: | Plastics, glass and metal |
| Features: | Contains a fluoropolymer for excellent adhesion and water resistance |
| Atomizer: | Ultrasonic |
| Pigment/Loading: | Gold nanoparticles @ 40wt% |
| Vehicle: | Aqueous-based |
| Resistivity: | 4.2E-4 to 1.9E-5 ohm-cm (30min @ 140C to 5min @ 225C) |
| Substrates: | Plastics, glass and metal |
| Features: | Contains a fluoropolymer for excellent adhesion and water resistance |
| Atomizer: | Ultrasonic |
