$165.00
JG-027UA-10 Gold Nanoparticle Ink
Conductive InksAerosol Conductive Inks| Deposition: | Aerosol |
| Vehicle: | Aqueous |
| Resistivity: | 4.2E-4 to 1.9E-5 ohm-cm |
| Substrates: | Plastics, glass and metal |
| Features: | Contains a fluoropolymer for excellent adhesion and water resistance |
| Printhead: | IDS NanoJet |
JG-027UA-10 is an electrically conductive gold nanoparticle ink designed to produce conductive traces on substrates such as paper, PET, glass, and polyimide. JG-027UA-10 ink is specially formulated for aerosol printing using ultrasonic atomization with the IDS NanoJet system. The ink contains a polymeric additive for improved adhesion to a variety of substrates. Cured prints are also resistant to water and isopropanol. Applications for the ink include general purpose printing as well as biomedical applications, high density interconnects, and fine line printing.
Technical Specs
| Pigment/Loading: | 10% w/w Au |
| Deposition: | Aerosol |
| Vehicle: | Aqueous |
| Resistivity: | 4.2E-4 to 1.9E-5 ohm-cm |
| Substrates: | Plastics, glass and metal |
| Features: | Contains a fluoropolymer for excellent adhesion and water resistance |
| Printhead: | IDS NanoJet |
