$100.00
JPT-710UA-P Platinum Nanoparticle Ink
Conductive InksAerosol Conductive Inks| Deposition: | Aerosol |
| Vehicle: | Aqueous |
| Resistivity: | 1.3E-3 to 3.7E-5 ohm-cm (150 – 1100 C curing temp range) |
| Substrates: | Plastics, glass, ceramics, metal |
| Features: | Noble metal ink for low and high temperature applications |
| Printhead: | IDS NanoJet |
Description
JPT-710UA-P is an electrically conductive platinum nanoparticle ink designed to produce conductive traces on substrates such as polyimide, glass, alumina, and silicon. JPT-710UA-P ink is specially formulated for aerosol printing using ultrasonic atomization with the IDS NanoJet system. The aqueous ink uses a polymeric binder and is intended for general purpose printing as well as biomedical, aerospace, and extreme high temperature environments.
Technical Specs
| Pigment/Loading: | 10% w/w Pt |
| Deposition: | Aerosol |
| Vehicle: | Aqueous |
| Resistivity: | 1.3E-3 to 3.7E-5 ohm-cm (150 – 1100 C curing temp range) |
| Substrates: | Plastics, glass, ceramics, metal |
| Features: | Noble metal ink for low and high temperature applications |
| Printhead: | IDS NanoJet |
Additional information
| Weight | 5 lbs |
|---|---|
| Dimensions | N/A |
| Deposition Method | Aerosol |
| Particle | Platinum nanoparticle |
| Loading (WT%) | 10 |
| Amount | 3mL |
| Vehicle | Aqueous |
| Resistivity (Ohm-cm) | 1.3E-3 to 3.7E-5 ohm-cm |
| Substrates | Ceramics, Glass, Metal, Plastic |
| Features | Noble metal ink for low and high temperature applications |
| Atomizer | Ultrasonic Atomization |
| Print Head | IDS NanoJet |
