Price range: $460.00 through $4,080.00
HPS-U11 Silver Nanoparticle Ink
Conductive InksScreen Print Conductive InksMetalon® Ultra series| Deposition: | Screen Print |
| Vehicle: | Butyl carbitol acetate |
| Resistivity: | As low as 4E-6 ohm-cm |
| Substrates: | Paper, plastics, metal, glass |
| Features: | High conductivity, fine line printing |
Description
HPS-U11 Silver Nanoparticle Ink offers very high conductivity for low temperature curing with excellent water and alcohol resistance. Ideal for paper, plastics, glass, and metals.
Technical Specs
| Deposition: | Screen print |
| Vehicle: | Butyl carbitol acetate |
| Resistivity: | As low as 4E-6 ohm-cm |
| Substrates: | Paper, plastics, metal, glass |
| Features: | High conductivity, fine line printing |
Additional information
| Weight | 5 lbs |
|---|---|
| Deposition Method | Screen Print |
| Ag Loading | 80% w/w Ag (HPS-U11), 76.5% w/w Ag (HPS-U11-LV) |
| Amount | 100g, 500g, 1kg |
| Packaging | Plastic Jar |
| Particle | Silver nanoparticle |
| Vehicle | Butyl carbitol |
| Curing Temp (C) | ≥ 100 |
| Resistivity (Ohm-cm) | As low as 4E-6 ohm-cm |
| Substrates | Glass, Metal, Paper, Plastic |
| Features | High conductivity, Fine line printing |
