Price range: $250.00 through $21,147.00
SPI-508 Silver Nanoparticle Ink
Conductive InksSpray Conductive Inks| Deposition: | Spray |
| Vehicle: | Aqueous-based |
| Resistivity: | 5.7E-6 to 1.7E-5 ohm-cm |
| Substrates: | Plastics, Paper |
| Features: | Produces cured films with high electrical conductivity, good scratch and abrasion resistance, and good adhesion. May be used in EMI / RF shielding, filter and membrane design for wastewater treatment, and as a seed layer for metal electroplating. |
Description
Water-based, silver nanoparticle spray ink SPI-508 produces cured films with high electrical conductivity, good scratch and abrasion resistance, and good adhesion. May be used in EMI / RF shielding, filter and membrane design for wastewater treatment, and as a seed layer for metal electroplating. Suitable substrates include plastics and label paper.
Technical Specs
| Pigment/Loading: | Silver nanoparticles (50 – 100 nm) @ 50 % wt. Ag |
| Vehicle: | Aqueous-based |
| Resistivity: | 5.7E-6 to 1.7E-5 ohm-cm |
| Substrates: | Plastics, Paper |
| Features: | Produces cured films with high electrical conductivity, good scratch and abrasion resistance, and good adhesion. May be used in EMI / RF shielding, filter and membrane design for wastewater treatment, and as a seed layer for metal electroplating. |
| Cleaning Fluid: | A solution of particle-free detergent and water |
Additional information
| Weight | 5 lbs |
|---|---|
| Dimensions | N/A |
| Packaging | Nalgene bottles |
| Amount (kg) | 0.1 kg, 0.2 kg, 0.5 kg, 1.0 kg, 1.5 kg, 2.0 kg, 2.5 kg, 3.0 kg, 3.5 kg, 4.0 kg, 4.5 kg, 5.0 kg, 5.5 kg, 6.0 kg, 6.5 kg, 7.0 kg, 7.5 kg, 8.0 kg, 8.5 kg, 9.0 kg, 9.5 kg, 10.0 kg, 11.0 kg, 12.0 kg, 13.0 kg, 14.0 kg, 15.0 kg, 16.0 kg, 17.0 kg, 18.0 kg, 19.0 kg, 20.0 kg |
| Cleaning Fluid | A solution of particle-free detergent and water |
